QMY4-30 Mobile Concrete block machine for sale

描述

QMY4-30  Introduction:

1. QMY4-30 Mobile Concrete block machine for sale suitable for small or medium-sized enterprises and individuals, who wants to make block in small investment.

2.As to the machine is not required large producing area, so customers can easily find a place to start the block production line. And it has been in the market for many years, so you don’t need to worry about the quality.

3. QMY4-30 Mobile Concrete block machine for sale  a compact machine with electric and hydraulic system, each procedure action locks with each other to guarantee the movable block making machinery operated safely, easily and dependably.

4.Through mold-releasing oil cyclinder, the mold box was locked into the vibration table with high rigidity to reach the synchronous vibration, so the concrete can be fluidified and exhausted in two or three seconds to ensure the high-density.

5.It can make many types hollow block, paver blokcs,solid blocks and curd stone by changing moulds.

6.The producing compressive strength can reach 16mpa (mpa) above, with high compactness, it is a good equipment for environmental protection and building.



Video In Tiktok :

@geothymachinery

QMY4-30 Small mobile hydraulic Block Machinery #blockmachine #smallbusiness

♬ original sound – block machinery – block machinery



Dimension	1420*1410*1210mm
Weight	900kgs
Power	5kw
Voltage	220V/380V or custom-made according to your local voltage
Power source	electric motor- can change to Siemens by custom-made
Warranty	One year
Material	fly ash, cinder, coal gangue and other industrial waste residue and river sand, gravel, cement, and other materials.
Shaping cycle	20-25s



Item	Size	Qty/Mold	Cycle Molding	Per Day /8 Hour
Hollow Block	400×200×200mm	4	20-25s	5800
Hollow Block	400×150×200mm	5	20-25s	7200
Hollow Block	400×100×200mm	9	20-25s	13000
